Trellix EX 3600 Email Security Server 1U Smart Node Sensor
Engineered for professionals who demand the best in performance, security, and design.
Up to 875 unique attachments per hour
1x 10/100/1000BASE-T port (Live Mode Analysis), 2x 10/100/1000BASE-T port (SMTP interface ports)
1x 10/100/1000BASE-T port
17.2" x 19.98" x 1.7" (437 mm x 507 mm x 43 mm)
Attackers use multi-stage phishing to steal credentials and spread emails internally, relying on social engineering, while ransomware often uses email delivery followed by command-and-control to trigger encryption.
Help your organization achieve unparalleled defense against credential harvesting and spearphishing attacks
MalwareGuard uses machine learning to score PE files for suspicious behavior, while Trellix IVX detonates email attachments and URLs to detect phishing and ransomware.
Real-time intelligence from the DTI Cloud to detect and respond to email threats, providing malware insights, attacker context, URL rewriting for safety, and retroactive detection of spearphishing and malicious links.
Full specifications for the model
| SKU | EX 3600 | EX 5600 | EX 8600 |
|---|---|---|---|
| Performance | Up to 875 unique attachments per hour | Up to 2,200 unique attachments per hour | Up to 3,300 unique attachments per hour |
| Network Interface Ports | 1x 10/100/1000BASE-T port (Live Mode Analysis) 2x 10/100/1000BASE-T port (SMTP interface ports) | 2x 1GigE BaseT | 4x SFP+ (1G SX, 10G SR, 1G LX, 10G LR, 10G CU, 1G T) |
| Management Ports | 1x 10/100/1000BASE-T port | 2x 1GigE BaseT | 2x 1GigE BaseT |
| IPMI Monitoring | Included | Included | Included |
| VGA Port (rear Panel) | Included | Included | Included |
| USB Ports (rear Panel) | USB2.0, USB3.2 | 2x USB3.1 Type A | 2x USB3.1 Type A |
| Serial Port (rear Panel) | DB9 (115,200 bps, No Parity, 8 Bits, 1 Stop Bit) | DB9 (115,200 bps, No Parity, 8 Bits, 1 Stop Bit) | DB9 (115,200 bps, No Parity, 8 Bits, 1 Stop Bit) |
| Storage Capacity | 4x 4TB HDD, RAID 10, 3.5 inch, FRU | 4x 4TB, RAID 10, HDD 3.5 inch, FRU | 4x 4TB, RAID 10, HDD 3.5 inch, FRU |
| Enclosure | 1RU, fits 19-inch Rack | 2RU, fits 19-inch Rack | 2RU, fits 19-inch Rack |
| Chassis Dimensions (WxDxH) | 17.2" x 19.98" x 1.7" (437 mm x 507 mm x 43 mm) | 19" x 26" x 3.5" (482.6 x 660.4 x 88.9 mm) | 19" x 26" x 3.5" (482.6 x 660.4 x 88.9 mm) |
| AC Power Supply | Redundant (1+1), FRU, 400W with Input 110-240VAC / 6.0–3.0A | 200-240VDC / 3.4–3.2A, 50-60 Hz IEC60320-C14 inlet | Redundant (1+1), FRU, 920W, 100-240V, 11–4.4A, 50-60 Hz IEC60320-C14 inlet | Redundant (1+1), FRU, 920W, 100-240V, 11–4.4A, 50-60 Hz IEC60320-C14 inlet |
| DC Power Supply | Not Available | Not Available | Not Available |
| Thermal Maximum Power | 1024 BTU/hr | 480 watts (1,637 BTU/hr) | 580 watts (1,978 BTU/hr) |
| Appliance Weight | 39.3 lbs | 44.1 lbs (20.0 kg) / 67 lbs (30.4 kg) | 44.1 lbs (20.0 kg) / 67 lbs (30.4 kg) |
| Compliance Safety | EN IEC 62368-1:2018+A11:2020; UL 62368-1; CSA 22.2 No. 62368-1; CNS 15598-1; IS 13252 (Part-1)/IEC 60950-1 | IEC 60950; EN 60950-1; UL 60950; CSA/CAN-C22.2 | IEC 60950; EN 60950-1; UL 60950; CSA/CAN-C22.2 |
| Compliance EMC | EN 55032:2015/A11:2020; EN 55035:2017/A11:2020; EN 61000-3-2:2014; EN 61000-3-3:2013; FCC CFR 47 Part 15; CAN ICES-003 | FCC Part 15 ICES-003 Class A; AS/NZS CISPR 22/32; EN 55032; EN 55024; IEC/EN 61000-3-2; IEC/EN 61000-3-3 | FCC Part 15 ICES-003 Class A; AS/NZS CISPR 22/32; EN 55032; EN 55024; IEC/EN 61000-3-2; IEC/EN 61000-3-3 |
| Environmental Compliance | Directive 2011/65/EU; CNS 15663 | RoHS Directive 2011/65/EU; REACH; WEEE Directive 2012/19/EU | RoHS Directive 2011/65/EU; REACH; WEEE Directive 2012/19/EU |
| Operating Temperature | 5°C to 35°C (41°F to 95°F) | 5°C to 35°C (41°F to 95°F) | 5°C to 35°C (41°F to 95°F) |
| Operating Relative Humidity | 8%–90% non-condensing | 5%–95% non-condensing | 5%–95% non-condensing |
| Operating Altitude | 0 to 5000 ft | 0 to 5000 ft | 0 to 5000 ft |
